Location: Main > Fiber Passive Components > PM Fiber Couplers Splitters

2x2 PM Fused Optical Couplers
P/N:PPC1 Series
Introduction:The fused fiber polarization maintaining coupler can either split the light from an input PM fiber between 2 output PM fibers, or can combine light signals from 2 PM input fibers into a single PM output fiber. The state of polarization can be aligned with either the slow axis or the fast axis of the PM fibers. The device can be used to split high power linearly polarized light into multiple paths without
perturbing the linear state of polarization (SOP). It can also be used as a power tap to monitor signal power in a PM fiber system without disturbing the linear SOP of the light propagating in the PM fiber. Applications include PM fiber interferometers, power sharing in polarization sensitive systems, and signal monitoring in PM fiber systems. The fused fiber technology allows for extremely high power handling of up to 2W. This compact device offers low excess insertion loss, low back reflection, and high extinction ratio. Split ratios from 1 to 50% are available.
P/N Keywords Unit Price Available Generate Quotation
PPC-55-2-50-B-1-P PM 1550nm, 2x2, Fused, 50:50, FC/UPC S$850.00/pc In stock Add to Request List


1x2 PM Thin Film Fiber Optical Coupler
P/N:PPC2 Series
Introduction:The fused fiber polarization maintaining coupler can either split the light from an input PM fiber between 2 output PM fibers, or can combine light signals from 2 PM input fibers into a single PM output fiber. The state of polarization can be aligned with either the slow axis or the fast axis of the PM fibers. The device can be used to split high power linearly polarized light into multiple paths without
perturbing the linear state of polarization (SOP). It can also be used as a power tap to monitor signal power in a PM fiber system without disturbing the linear SOP of the light propagating in the PM fiber. Applications include PM fiber interferometers, power sharing in polarization sensitive systems, and signal monitoring in PM fiber systems. The fused fiber technology allows for extremely high power handling of up to 2W. This compact device offers low excess insertion loss, low back reflection, and high extinction ratio. Split ratios from 1 to 50% are available.
P/N Keywords Unit Price Available Generate Quotation
PPC-55-1-10-2 PM 1550nm Panda,1x2,Thin Flim,10:90,PM FC/APC S$1,020.00/pc In stock Add to Request List
PPC-55-1-50-1 PM 1550nm Panda,1x2,Thin Film,50:50,PM FC/UPC S$950.00/pc In stock Add to Request List
PPC-55-1-50-2-H PM 1550nm Panda,1x2,2W,Thin Film,50:50,PM FC/APC S$1,060.00/pc Call us Add to Request List

[First] [Previous] [Next] [Last]
Goto page
This is Page 1 of total 1pages
Total 2 types, 10 types/page
