| Name: | DIA10mm 1064nm Plano-Convex Lens EFL+8mm |
| P/N: | POL-SF19-PCX-D10-F8-1064 | | Keywords: | Dia10mm,SF19,EFL8mm,DAR@1064nm |
| Unit Price: |
S$80.00/pc
|
| Available: |
In stock
|
| Request: |
Add to Request List |
| Introduction: | Schott material, N-SF19, 667331.290.
Refractive index 1.667
Abbe number: 33.12
Plano convex lens design |
|
|
 |
| Material: |
Schott N-SF19 |
| Wavelength Range: |
1064nm designed with spherical, plano convex |
| Diameter: |
10.0,+0.0/-0.1mm |
| Focal Length: |
8.0mm (+/-1%) |
| Radius of S1: |
5.12mm convex surface |
| Radius of S2: |
plano/flat |
| Central thickness: |
5.8mm |
| Edge thickness: |
1.92mm |
| Scratch/Dig: |
20/10 |
| Centration: |
<=3 arc min |
| Clear Aperture: |
>90% |
| Coating: |
Double side AR Coated at 1064+/-10nm, R<0.2% max | |
| |
