Location: Main > Optical Substrates > Quartz Substrates Plates Wafers > QUZS-E-R0205-0900C

Name:	DIA20.5xH9.0mm Quartz Glass Rod(Clear)
P/N:	QUZS-E-R0205-0900C
Keywords:	Dia20.5xH9.0mm,China JGS2 glass;Clear;MOQ5000pcs
Unit Price:	S$00.60/pc
Available:	In stock
Request:	Add to Request List
Introduction:	QUZS Fused Quartz Glass Substrates or Windows E 100-80 Scratch and Dig (Double Side Typ.) < Lambda @ 632.8nm over 1-inch area on-jig tested

Substrate Material:	Fused quartz (250 -2500nm) - China JGS2 glass
Outer Diameter:	Rod Dia 20.5, -0.2/+0mm
Height:	9.0,+/-0.2mm total height
Surface Quality:	100-80 scratch and dig, both surfaces all commercial polished
Flatness:	< Lambda @ 632.8nm over 1-inch area on-jig tested
Parallelism:	<10 arc minutes
Cylidrical Surface:	Clear surface - fire polished
Chamfer:	Standard protection chamfer <0.2 - 0.3mm x45deg
Coating:	all surfaces without coating
Applications:	General purpose, as glass holder or substrate use for glass filters and mirrors
MOQ:	MOQ5000pcs per lot process(minimum order quantity) Note: contact us (sales@optics.sg ) for quote(sample order)
